Product Title (Name): 10.1'' Indoor Wall Mount Display - FHD Industrial-Grade Digital Signage with Multi-OS Support
- Overview
- Recommended Products
Product General Information
| Place of Origin | CHINA |
| Brand Name | AWSTOUCH |
| Model Number | A10-IPB01 |
| Certification | CE,RoSH |
Product Introduction
Quick Detail:
Alternative Names of the Product
•Indoor Wall Mount Digital Signage
•Compact Advertising Display
•Indoor LCD Signage
•Desktop Wall-Mounted Terminal
•Multi-Format Media Display
Main Applications
•Retail Stores: Showcase product promotions, discounts, and new arrivals at store entrances or product shelves to attract customer attention.
•Offices & Corporate Spaces: Display company culture, internal announcements, and meeting schedules in lobbies or corridors for employees and visitors.
•Hotels & Hospitality: Provide room information, service guides, local travel recommendations, and event notices for hotel guests.
•Financial Institutions: Share financial news, service introductions, queue status, and safety tips in bank lobbies.
•Educational Institutions: Display campus notices, course schedules, activity promotions, and educational content in school hallways or classrooms.
Description
The 10.1'' Wall Mount Display is a compact, high-performance indoor digital signage designed for commercial and public indoor spaces. Equipped with FHD (1280x800) resolution and 300-500 nits brightness, it delivers clear, vivid visuals that stand out in various indoor environments. Adopting industrial-grade hardware, the display ensures stable 24/7 operation, meeting the long-hour working demands of retail, office, hotel, and educational scenarios. It offers versatile operating system options (Standalone/Android/Windows) to fit different functional needs and budget requirements, supporting multi-format media playback including JPG, PNG, BMP images and AVI, MP4, MOV videos. With a space-saving wall-mount design, it optimizes limited indoor space while enabling easy installation. The display features user-friendly functions such as automatic file playback, USB content update, timer on/off, and remote control support, simplifying content management and daily maintenance. Additionally, rich optional functions (Thermal Printer, NFC reader, 2D/Bar code Scanner, etc.) allow personalized customization to adapt to diverse application scenarios, making it an ideal advertising and information dissemination solution for small to medium-sized indoor venues.
Applications
Retail Stores，Offices & Corporate Spaces，Hotels & Hospitality，Financial Institutions，Educational Institutions
Specifications
| 10.1 Wall Mount Display | 10.1 Wall Mount Display |
| Specification | Specification |
| Model | A10-IPB01 |
| Screen Size | 10.1 inch |
| Active Display Area (mm) | 224.64mm(W)×126.36mm(H) |
| Display Mode | 16:09 |
| LCD Type | TFT-LCD |
| Resolution | 1280×800 |
| Display Color | 16.7M |
| Brightness (nits) | 300nits~500nits |
| Brightness Control | Manual/Automatic optional |
| Contrast Ratio | 1200:01:00 |
| Viewing Angle | 178°(H) / 178°(V) |
| Response Time | 6ms |
| Backlight | LED backlight |
| Touch type | Capacitive touch |
| Transparency | 90% |
| Scanning Speed | 40Scans/S |
| Response Speed | <10ms |
| Touch precision | 1mm |
| Minimum Touch | 5 points (optional) |
| Operation Parameters | Operation Parameters |
| Operating System | Standalone (no system) / Android 11.0 / Android 12.0 / Windows 10/11 |
| Working Humidity | 10% to 85% (non-condensing) |
| Storage Humidity | 5% to 90% (non-condensing) |
| Temperature Control System | Natural heat dissipation (industrial-grade heat dissipation structure) |
| Power Supply | AC 100V-240V, 50HZ/60HZ |
| Power Consumption | 30W~60W (varies by configuration) |
| Main Function | Playing file automatically |
| With USB update | |
| Support HD video, pictures and music | |
| Security and password protection | |
| Set up time on/off | |
| Support Remote controller | |
| Support Safety lock system | |
| Smart Control System | Industrial-grade power switch |
| Built-in 5W*2 speakers | |
| Overload protection | |
| Timer | |
| Cooling & Heating System | Natural heat dissipation, optimized heat dissipation structure |
| Temperature | Storage: -20 Celsius degree to 60 Celsius degree |
| Working: 0 Celsius degree to 40 Celsius degree | |
| Fixing Method | Wall Mount |
| Color | Black color/white color/gray color optional |
| Protection Glass | 4mm Tempered glass |
| Applicable Field | Indoor public places, Retail stores, Offices, Hotels, Banks, Schools, Commercial buildings etc. |
| Available Operating Systems | Available Operating Systems |
| Standalone version (no system) | 1*USB、1*SD、1*HDMI |
| Android version | RK3568A Quad Core, 4G RAM+32G ROM, Android 11.0，wifi, Bluetooth supported, 2.0GHz，I/O：HDMI+USB OTG+USB HOST+LAN+AUDIO+TF |
| RK3399E Hexa Core, 4G RAM+32G ROM, Android 11.0，wifi, Bluetooth supported, 2.0GHz，I/O：HDMI+USB 3.0+LAN+AUDIO+TF+SIM | |
| RK3588A Octacore, 8G RAM+64G ROM, Android 12.0，wifi, Bluetooth supported, 2.2GHz，I/O：HDMI+USB 3.0+USB OTG+LAN+AUDIO+TF+SIM | |
| Windows version | Intel i3 CPU, 8G RAM, 128G SSD, integrated GPU, wifi, RJ45 supported, Windows 10/11，I/O：HDMI+VGA+2USB3.0+1USB2.0+LAN+AUDIO |
| Intel i5 CPU, 8G RAM, 128G SSD, integrated GPU, wifi, RJ45 supported, Windows 10/11，I/O：HDMI+VGA+2USB3.0+2USB2.0+LAN+AUDIO | |
| Intel i7 CPU, 8G RAM, 128G SSD, integrated GPU, wifi, RJ45 supported, Windows 10/11，I/O：HDMI+VGA+2USB3.0+2USB2.0+LAN+AUDIO |
Competitive Advantage
•Space-Saving Wall-Mount Design: Compact 10.1-inch size and wall-mount installation optimize indoor space utilization, perfect for small to medium-sized venues with limited space.
•Industrial-Grade Stability: Adopts industrial-grade motherboard and hardware components, ensuring reliable 24/7 operation and long service life in high-frequency usage scenarios.
•Versatile Configuration: Multiple processor (Singlechip/RK3568A/RK3399E/RK3588A/Intel i3/i5/i7) and system options meet different performance, functional and budget requirements.
•Rich Expansion Options: Optional Thermal Printer, NFC reader, RFID Card reader, 2D/Bar code Scanner and other modules support personalized customization for diverse business needs.
•User-Friendly Operation: Simple USB content update, remote control, and timer on/off functions reduce manual operation costs; intuitive interface enables quick setup and use.
Tag
Wall Mount Display，Indoor Advertising Display，Compact Digital Signage，Industrial-Grade Media Player，FHD Indoor Signage
