Product General Information
Place of Origin |
CHINA |
Brand Name |
AWSTOUCH |
Model Number |
A43-FS002 |
Certification |
CE, RoSH, FC, ISO9001 |
Product Introduction
Quick Detail:
•43" Capacitive Touch Inquiry Kiosk
•Floor-Standing Interactive Information Terminal
•FHD Touch Screen Self-Service Kiosk
•Multi-OS Indoor Touch Query Terminal
•Capacitive Touch Interactive Kiosk
Description:
The 43" Capacitive Touch Kiosk (Model: A43-FS002) is a user-centric interactive terminal designed for indoor inquiry and self-service scenarios. Featuring a 43-inch FHD (1920×1080) display with 300nits brightness, it delivers clear, vivid visuals with wide 178° viewing angles, ensuring content visibility from all positions. Equipped with a 5-point capacitive touch screen, it offers precise response (<10ms) and smooth operation, supporting intuitive human-machine interaction for users of all ages. The floor-standing design combines stability and sleek aesthetics, with an adjustable height feature to fit different usage environments, seamlessly integrating with retail stores, hospitals, government halls, and corporate lobbies.
Powered by flexible operating system options (Android 11.0 / Windows 10 Pro), the kiosk supports customized inquiry software, seamless playback of HD media (videos, images, audio), and convenient content updates via USB or remote control. Built with premium components and optimized heat dissipation structure, it ensures long-term stable operation even under high-frequency touch usage. User-friendly functions include scheduled on/off, password protection, anti-theft lock, and built-in 5W×2 speakers, simplifying daily management and reducing maintenance costs. Rich optional expansion modules (NFC Reader, 2D Barcode Scanner, Thermal Printer) are available to meet personalized needs, making it a versatile solution for self-service inquiry, information dissemination, and interactive service in various indoor venues.
Applications:
•Retail Malls: Provide store navigation, product information, promotion browsing, and membership service inquiry for shoppers.
•Hospitals: Offer registration guidance, department navigation, medical information inquiry, and queue status display to enhance service efficiency.
•Government Service Halls: Deliver business process guidance, document verification, and public information release, reducing manual consultation pressure.
•Educational Institutions: Support campus navigation, course inquiry, event promotion, and student service information lookup.
•Corporate Lobbies: Display company information, meeting schedules, and visitor reception services for employees and guests.
Specifications:
43" Capacitive Touch Kiosk |
43" Capacitive Touch Kiosk |
Specification |
Specification |
Model |
A43-FS002 |
Screen Size |
43 inch |
Active Display Area (mm) |
941.18mm(W)×529.42mm(H) |
Display Mode |
16:9 |
LCD Type |
TFT-LCD |
Resolution |
1920×1080 (FHD) |
Display Color |
16.7M |
Brightness (nits) |
300nits |
Brightness Control |
Manual/Automatic optional |
Contrast Ratio |
1200:1 |
Viewing Angle |
178°(H) / 178°(V) |
Response Time |
6ms |
Backlight |
LED backlight |
Touch Screen |
Standard 5-point Capacitive Touch (PCAP) |
Touch Response Speed |
<10ms |
Touch Precision |
1mm |
Operating System |
Android 11.0 / Windows 10 Pro |
Working Humidity |
10% - 85% (non-condensing) |
Storage Humidity |
5% - 90% (non-condensing) |
Temperature Control System |
Efficient natural heat dissipation |
Power Supply |
AC 100V-240V, 50HZ/60HZ |
Power Consumption |
150W (max) |
Working Temperature |
0℃ - 40℃ |
Storage Temperature |
-20℃ - 60℃ |
Fixing Method |
Floor-Standing (height adjustable) |
Color |
White/Black/Gray (optional) |
Protection Glass |
3mm Tempered Glass (anti-glare & anti-fingerprint) |
Main Functions |
Touch interactive inquiry, USB/remote content update, scheduled on/off, password protection, anti-theft lock, built-in speakers |
Available operating |
Quad Core, RK3568 chipset, 4G RAM+32G ROM, Android 11.0 wifi, Bluetooth supported, 2.0GHz I/O：HDMI+USB OTG+USB 3.0+LAN+AUDIO+TF Hexa Core,RK3399E，4G RAM+32G ROM, Android 11.0，wifi, Bluetooth supported, 2.0GHz，I/O：HDMI+USB 3.0+LAN+AUDIO+TF+SIM Octa Core, RK3588A chipset, 8G RAM+64G ROM, Android 12.0 wifi, Bluetooth supported, 2.2GHz I/O：HDMI+USB 3.0+USB OTG+LAN+AUDIO+TF |
|
PC Version |
Intel i3 CPU, 8G RAM, 128G SSD, integrated GPU, wifi, RJ45 supported, Windows 10/11，I/O：HDMI+VGA+2USB3.0+1USB2.0+LAN+AUDIO Intel i5 CPU, 8G RAM, 128G SSD, integrated GPU, wifi, RJ45 supported, Windows 10/11，I/O：HDMI+VGA+2USB3.0+2USB2.0+LAN+AUDIO Intel i7 CPU, 8G RAM, 128G SSD, integrated GPU, wifi, RJ45 supported, Windows 10/11，I/O：HDMI+VGA+2USB3.0+2USB2.0+LAN+AUDIO |
Competitive Advantage:
•Large 43" FHD Display: 1920×1080 resolution and 450nits brightness deliver clear, eye-catching visuals, ideal for detailed information display in indoor spaces.
•Precise Capacitive Touch: 5-point touch with <10ms response speed ensures smooth, intuitive interaction, enhancing user experience.
•Flexible OS Options: Supports Android 11.0 and Windows 10 Pro, compatible with various customized software and application scenarios.
•Stable & Durable Design: Premium components and optimized heat dissipation enable long-term reliable operation, adapting to high-frequency touch usage.
•Easy Operation & Maintenance: USB/remote content update, scheduled on/off, and simple calibration functions reduce management costs.
•Versatile Applications: Suitable for retail, healthcare, government, education, and corporate sectors, meeting diverse inquiry and self-service needs.
Tag:
43" Touch Kiosk, Capacitive Touch Inquiry Terminal, Floor-Standing Interactive Terminal, FHD Indoor Touch Kiosk, Multi-OS Self-Service Terminal
